PTC Markov (formerly Relex Markov)

is a visual interface that allows manufacturers to construct a state transition diagram to model complex systems. Since these systems are designed with a wide range of redundancy, interdependency and sequence dependent failures, their analysis needs exceed the scope of standard, series-based modeling tools.

With its robust state transition diagramming tools and intuitive interface, PTC Windchill Markov enables users to create graphical representations and models of complex system states and their associated interconnections. By leveraging each diagram, it is possible to calculate system performance metrics, including capacity, reliability and availability for different states.

Advanced Modeling Capabilties.  Windchill Markov provides graphical modeling for systems that exhibit dynamic behavior, sequence dependency and components with inter-dependencies, where future performance is determined solely by its current state. Represent a system in operational, degraded and failed states, with dynamic failure and repair rates. Windchill Markov considers systems with complex repair or restart procedures or complex common cause failures, and is able to account for consequences related to switchover mechanisms, repair priorities, limited repair resources, and failure sequence dependency.

cache_888071381

Powerful Calculations.  Windchill Markov utilizes a powerful Markov engine that supports both transient and steady-state analysis results. Calculate MTBF (Mean Time Between Failures), MTTF (Mean Time to Failure) and MTTR (Mean Time to Repair), along with a range of other reliability metrics including capacity, reliability and availability, failure frequency, cost and frequency of visits of a state. Consider associated costs in terms of currency, functionality or throughput. Dynamically link results to Windchill FTA to greatly expand analytical capabilities.

Professional Outputs. Windchill Markov is supplied with a range of industry standard reports and graphs. Easy-to-use Report and Graph Wizards provide complete user customization of outputs to fit your specific needs, without the need for IT experts. Once complete, reports and graphs can be printed or saved directly to Microsoft Word or Excel, and Adobe PDF.



Windchill Markov

Technical Highlights

Supported Calculations

  • Availability
  • Reliability
  • MTBF
  • Capacity
  • Cost
  • Conditional failure intensity
  • Conditional repair intensity
  • Failures, departures, transitions and visits metrics
  • Uptime and downtime
  • Many others
Modeling Featuresions

  • Standby failures
  • Non-standard common cause failures
  • Induced failure and shared load systems
  • Imperfect fault coverage and switchover mechanisms
  • Repair priorities
  • Limited repair resources
  • Failure sequence dependent consequences



Calculation Parameters

  • Start time
  • End time
  • Number of data points
  • Time point results
  • Required capacity
  • Precision
  • Detection of non-absorbing states
Dynamic Data Links

  • Windchill FTA








Download the Windchill Markov Data Sheet

Windchill_Markov
